CUTTING SYSTEM | |
Cutting width | 122 cm |
Cutting deck type | 7-gauge fabricated |
Cutting methods | Collect/Mulch/Side discharge |
Cutting deck material | Steel |
Deck thickness | 4.76 mm |
Cutting height steps | 14 |
Blade engagement | Electric clutch |
Clutch rating | 271.16 Nm |
Blade-tip speed | 18,500 m/s |
Blades | 3 pcs |
Anti-scalp wheels | 3 |
Nose roller | No |
Powder-coated cutting deck | Yes |
Spindle/mandrel type | Cast iron |
Greasable mandrels | Yes |
Deck Wash Port | No |
| |
CAPACITY | |
Productivity | 14,973.4 m²/h |
Speed forward max | 17.7 km/h |
Speed forward min | 0 km/h |
| |
DIMENSIONS | |
Base machine, height | 122 cm |
Base machine, length | 145 cm |
Base machine, width (chute down) | 157.5 cm |
Base machine, width (chute up) | 127 cm |
Weight | 517.1 kg |
| |
DRIVE SYSTEM | |
Transmission type | Pump/Wheel motor |
Transmission manufacturer | Parker |
Transmission model | HP1/DL |
Pump displacement | 12 cm³ |
Fan-cooled pumps | Yes |
| |
ENGINE | |
Motor/engine manufacturer | Kawasaki |
Power Output | 18.3 kW |
Engine name | FX Series |
Cylinder displacement | 852 cm³ |
Cylinders | 2 |
Engine cooling | Air |
Air filter type | Heavy-Duty Canister Style |
Power/fuel type | Gasoline |
Engine lubrication type | Full pressure with oil filter |
Oil filter | Yes |
Fuel tank volume | 26.5 l |
Fuel tank location | Side (Single) |
| |
EQUIPMENT | |
Seat material | Vinyl |
Seat back height | High |
Hour meter type | Yes |
Cup holder | Yes |
Seat type | Professional |
