ENGINE | |
Power/fuel type | Gasoline |
Net power at preset rpm Energy | 9.8 kW |
Motor/engine manufacturer | Kawasaki |
Engine name | FS Series V-Twin |
Cylinder displacement | 603 cm³ |
Cylinders | 2 |
Engine cooling | Fan/Air |
Engine lubrication type | Full pressure |
Oil filter | Yes |
| |
EMISSION | |
Exhaust emissions (CO2 EU V) | 851 g/kWh |
| |
BATTERY | |
Battery capacity | 24 Ah |
Battery type | Lead-Acid |
Battery pack weight | 7.2 kg |
Battery manufacturer | Global |
| |
CUTTING DECK | |
Uncut circle | 30 cm |
Cutting width, min | 94 cm |
Cutting width, max | 112 cm |
Cutting height min | 25 mm |
Cutting height max | 75 mm |
Blade engagement | Automatic |
| |
DIMENSIONS | |
Tyre dimensions, front | 170/60-8 |
Tyre dimensions, rear | 170/60-8 |
Wheelbase | 88.7 cm |
Ground clearance | 105 mm |
Base machine, length | 200.8 cm |
Base machine, width | 88.3 cm |
Base machine, height | 115 cm |
Gross weight towed | 115 cm |
| |
DRIVE SYSTEM | |
PTO (Power Take Off) | Belt-driven |
Transmission type | Hydrostatic |
Transmission manufacturer, rear | Tuff Torq |
Drive method | Dual pedal-operation |
Speed forward max | 9.5 km/h |
Speed reverse max | 5.9 mph |
Speed reverse max | 9.5 km/h |
Transmission manufacturer, front | Tuff Torq |
Transmission model, front | KTM10LB |
Transmission model, rear | K574RA |
| |
EQUIPMENT | |
Seat suspension | Yes |
Hour meter type | Digital with pre-programmed service intervals |
Seat material | PU |
Seat back height | High |
Foldable seat | Yes |
Steering wheel type | Comfort |
Parking brake, type | Disc |
| |
VIBRATION | |
Vibration level steering wheel | 2.5 m/s² |
Vibration level seat | 0.7 m/s² |
| |
SOUND AND NOISE | |
Sound pressure level at operators ear | 84 dB(A) |
Sound power level, guaranteed | 99 dB(A) |
Sound power level, measured | 98 dB(A) |
